*Brand NEW* Weinview MT8100iE/MT8101iE/MT8102 1WV Touchscreen Power Adapter / 24V Charger Power Supply
Product Overview
Weinview MT8100iE/MT8101iE/MT8102 1WV Touchscreen Power Adapter / 24V Charger
Weinview Touch Screen MT8100iE/MT8101iE 1WV Power Adapter (DC 24V 650mA Transformer)
Weintek MT8100iE/MT8101iE 1WV Touchscreen Power Adapter (DC 24V, 3-Pin Phoenix Connector)
This industrial AC-DC switching power adapter is designed as a direct replacement power supply for **Weinview (Weintek) MT8100iE & MT8101iE 10.1-inch HMI touch screens**. It provides stable regulated 24V DC, rated output 650mA (15.6W), adopting industrial low-ripple EMI suppression circuit. Effectively avoids screen flickering, communication instability and unexpected HMI restart on automation production lines. Supports 24/7 continuous industrial operation, conforms to Level VI energy efficiency and IEC 61010 industrial control equipment safety standards.

## Full Technical Specifications

- Compatible HMI: Weinview MT8100iE, MT8101iE Touch Screen
- Rated Power: 15.6W Max
- AC Input: 100–240V AC 50/60Hz universal wide global voltage
- DC Output: 24.0V DC, continuous rated 0.65A (650mA)
- DC Connector: Standard round barrel plug (5.5mm OD × 2.1mm ID, **Center Positive Polarity**)
- AC Interface: IEC C14 desktop input socket, matched with detachable 3-pin mains cord
- Efficiency Grade: Level VI high energy efficiency, low standby power loss
- Cooling Structure: Fanless multi-slot passive natural convection, zero electrical noise interference
- Housing Material: Thickened flame-retardant matte black industrial ABS shell
- Safety Certifications: CCC, CE, FCC, RoHS, LPS Limited Power Source, IEC 61010
- Built-in Industrial Protections: OVP overvoltage, OCP overcurrent, SCP short-circuit, OTP overheating, automatic hiccup recovery
- Usage Restriction: Indoor industrial cabinet / control panel use only

## Compatible Devices

1. Weinview MT8100iE 10.1-inch industrial touch HMI
2. Weinview MT8101iE 10.1-inch human-machine interface
3. Other small industrial controllers, signal modules requiring 24V 650mA DC power with center-positive round barrel port

## Core Product Advantages

✅ Matches the power requirement of MT8100iE / MT8101iE exactly, stable 24V 650mA continuous output, plug-and-play replacement for original damaged power adapter
✅ Standard center-positive barrel connector fits the HMI power jack tightly; prevents intermittent power failure caused by cabinet vibration
✅ Industrial ultra-low ripple output suppresses electromagnetic interference, ensures stable PLC communication and eliminates touch screen flicker
✅ Fanless silent design avoids additional noise interference in automated workshop environments
✅ LPS limited power source certification improves safety for unattended long-running industrial equipment
✅ Level VI high-efficiency circuit reduces heat accumulation and power consumption inside control cabinets
✅ Universal wide-range AC input works with global mains, suitable for cross-border automation equipment after-sales matching
✅ Complete multi-layer self-recovery safety protection prevents permanent damage to HMI mainboard caused by grid surges and wiring short-circuits
Packing list:
1 x AC DC Adapter Power Adapter
1 x US UK EU AU Power Cable Free fit your country
Condition NEW New 1 Year Warranty 30-Days Money Back!
